Question 1.3 (20 Points): Given a concrete floor of frame structure having a size of 27 m× 27 m with the column grid of

[answerhappygod]

Question 1 3 20 Points Given A Concrete Floor Of Frame Structure Having A Size Of 27 M 27 M With The Column Grid Of 1 (131.43 KiB) Viewed 38 times

Sub: Design Of Concrete Structure.Please solved Number 2 question properly.Thank in advance.
Question 1.3 (20 Points): Given a concrete floor of frame structure having a size of 27 m× 27 m with the column grid of 9 m×9 m in both longitudinal and transvers directions. Considering the floor system, two different plan arrangements have been proposed as shown in Fig. 1(a) and (b), respectively. The density load of floor layer is 5.0kN/m2, live load on floor is 4.0kN/m2 and the density load of beam is 4.5kN/m (Note: all are design values). (2) For plan arrangement B, please firstly draw the representative calculation unit of concrete slab, and then calculate and draw the dead and live loads applied on the slab (in two respective figures). (a): Plan arrangement A (b): Plan arrangement B Fig. 1 Plan arrangements of floor system for Question 1.3
