<Sec. 1.6-8 Normal Stress, Shear Stress, Bearing Stress, and Embedment Length < 5 of 12 As shown mass of weight Wis suspended from one end of the control arm ABC Two brackets support the bearing pin at point 8e the pin is subjected to double shear) The connection at point C ngid and only experiences a horizontal force component Leta 2.0 mb 40m. d-250 mm al 100 mm, and W-50 kN
Normal Stress, Shear Stress, Bearing Stress, and Embedment Length Y Part B - Required strength of bearing pin ▼ Find the required strength Trail of the bearing pin given that the factor of safety is F. S. = 3. Express your answer in kilopascals to three significant figures. ▸ View Available Hint(s) 15.ΑΣΦ. 11 Ivec Tfall 1.71 104 Submit Previous Answers X Incorrect; Try Again; 5 attempts remaining Part C - Required embedment length ? kPa
ormal Stress, Shear Stress, Bearing Stress, and Embedment Length Y Part C-Required embedment length Find the required embedment length, L. given that the ultimate bonding stress between the wall and rod is 500 MPa and the factor of safety is F.S. -1 Express your answer in meters to three significant figures. > View Available Hint(s) L= Submit 195| ΑΣΦ/11 Ivec Part D-Required bearing bracket thickness E Find the required bearing bracket thickness, t. given that all 500 MPa and the factor of safety is F. S.-3. Express the required bearing bracket thickness in meters to three significant figures. View Available Hint(s) 2
