2.3 A DC voltmeter (scale set to 20 V) is used to measure the voltages across a resistor (470 resistor with a 10% tolera

[answerhappygod]

2 3 A Dc Voltmeter Scale Set To 20 V Is Used To Measure The Voltages Across A Resistor 470 Resistor With A 10 Tolera 1 (37.72 KiB) Viewed 40 times

2.3 A DC voltmeter (scale set to 20 V) is used to measure the voltages across a resistor (470 resistor with a 10% tolerance). The voltmeter displays a true voltage of 12 V when measuring the input to the resistor, and a voltage of 9 V when measuring its output to ground. The voltmeter has an accuracy of approximately 5%. 2 ASSIGNMENT 2 FOR 2022 - METROLOGY III 2.3.1 Calculate the average power (in dBm) dissipated in the resistor. (4) 2.3.2 Calculate the voltage and current error as a percentage. 2.3.3 Calculate the maximum power dissipation in the resistor. 2.3.4 Calculate the minimum power dissipation in the resistor. ග (1) (1)
