calculate for what is asked i have observed in correct answer from previous answers
2.48 A compound bar shown in Fig. 2.72 consists of a 30 mm diameter steel rod encased per tube of internal diameter 30 mm and external diameter 40 mm. Find the stresses produced steel and copper rod when a load of 100 N falls from a height of 40 mm. Take E, = 2 × 10 N/mm², E-1.0 10 N/mm². Solution 100 N- 800 mm 40 mm Fig. 2.72 Steel Rod Copper Tube
