An unsupported slope is shown in Fig. E-18.9. Determine the factor of safety against sliding for the trial slip surface.

Post by answerhappygod »

An Unsupported Slope Is Shown In Fig E 18 9 Determine The Factor Of Safety Against Sliding For The Trial Slip Surface 1
An Unsupported Slope Is Shown In Fig E 18 9 Determine The Factor Of Safety Against Sliding For The Trial Slip Surface 1 (32.9 KiB) Viewed 40 times
An unsupported slope is shown in Fig. E-18.9. Determine the factor of safety against sliding for the trial slip surface. Take c = 50 kN/m², and = 0. The weight of the wedge ABD is 2518 kN and acts at a horizontal distance of 11 m from the vertical AO. Solution. Length of are 2 x 24 x 65 24 14m 50* -11m- r=24m
Join a community of subject matter experts. Register for FREE to view solutions, replies, and use search function. Request answer by replying!
