Question 17 Refer to the figure below: Given: BC-75 mm wide x 10 mm thick strut AD-100 mm wide x 10mm thick rigid bar Th

Post by answerhappygod »

Question 17 Refer To The Figure Below Given Bc 75 Mm Wide X 10 Mm Thick Strut Ad 100 Mm Wide X 10mm Thick Rigid Bar Th 1
Question 17 Refer To The Figure Below Given Bc 75 Mm Wide X 10 Mm Thick Strut Ad 100 Mm Wide X 10mm Thick Rigid Bar Th 1 (40.58 KiB) Viewed 40 times
Given:
BC = 75 mm wide x 10 mm thick strut
AD = 100 mm wide x10mm thick rigid bar
The figure also shows the typical connection at all joints.
Calculate the bolt stress at B if its diameter is 20mm.
Question 17 Refer to the figure below: Given: BC-75 mm wide x 10 mm thick strut AD-100 mm wide x 10mm thick rigid bar The figure also shows the typical connection at all joints. Calculate the bolt stress at B if its diameter is 20mm. O ALEMPA 21.6 MP O 45.8 MP O 15.3MPa 1.20 m B 1.20 m C P typical connection 1.20 m D 2.40 KN
Join a community of subject matter experts. Register for FREE to view solutions, replies, and use search function. Request answer by replying!
