L₁/2 PO L₁ B L₂ The beam above is pin supported at A, and there is a roller at B. The beam spans a distance of L₁, and t

[answerhappygod]

L 2 Po L B L The Beam Above Is Pin Supported At A And There Is A Roller At B The Beam Spans A Distance Of L And T 1 (26.41 KiB) Viewed 29 times

L₁/2 PO L₁ B L₂ The beam above is pin supported at A, and there is a roller at B. The beam spans a distance of L₁, and then the beam cantilevers beyond B by an amount L2. There are two loads, each downward and with a magnitude of P: one acting at the mid-span of the L₁ span, and the other acting at the tip of the cantilever. P = 32.4 KN L₁19.00 m Question ID: 98,443 L₂= 6.08 m Assuming up to be positive, what is the value of the vertical reaction at A?
