3. (14 %) The operations of a differential decoder at the receiver is defined as: (1) If the incoming adjacent bits are

[answerhappygod]

3 14 The Operations Of A Differential Decoder At The Receiver Is Defined As 1 If The Incoming Adjacent Bits Are 1 (109.56 KiB) Viewed 29 times

3. (14 %) The operations of a differential decoder at the receiver is defined as: (1) If the incoming adjacent bits are identical to each other, the original signal is 1. (II) If the incoming adjacent bits are complement to each other, the original signal is 0. Please find: (a) (5 %) When we received 00101110001, what is the original bit sequence if the rightmost bit is the first bit? (b) (9 %) Please design such a decoder by using some logic gates and a delay buffer which can delay the incoming bit sequence by 1 bit time.
