With the ongoing extension of Manila Skyway, a series of 250 mm diameter circular poles are to be used as vertical member each carrying a compressive load of 3 kN acting 100 mm from centroidal axis of cross section and a lateral load of 0.45 kN at its top If the height and the unit weight of the pole is 3 m and 22 kN/m³, respectively, Determine the maximum compressive stress at the base of the pole Select the correct response. 1.20 MPa 0.95 MPa 1.03 MPa 1.14 MPar
