For the following hyperstatic truss structure, determine thestress in the chords 1-4, 1-2 and 2-4 using the matrixmethod.We give:
E = 200 GPa
Areas of the sections:1−2 = 250 mm^2
1−4 = 200 mm^2
1−3 = 200 mm^2
2−3 = 150 mm^2
3−4 = 200 mm^2
2−4 = 250 mm^2
5−4 = 100 mm^2
Notes:Respect the numbering of the nodes.It is mandatory to consider the following directions for thechords:1=>2; 1=>4; 1=>3; 2=>3; 3=>4; 2=>4
For The Following Hyperstatic Truss Structure Determine The Stress In The Chords 1 4 1 2 And 2 4 Using The Matrix Meth 1 (60.14 KiB) Viewed 48 times
