10. A grillage of 3 beams is used to span an opening 3L by 2L as shown in Fig. 10. The second moment of area of the long
-
answerhappygod
- Site Admin
- Posts: 899603
- Joined: Mon Aug 02, 2021 8:13 am
10. A grillage of 3 beams is used to span an opening 3L by 2L as shown in Fig. 10. The second moment of area of the long
10. A grillage of 3 beams is used to span an opening 3L by 2L as shown in Fig. 10. The second moment of area of the longer beam is 3 times that of the shorter beams. For the loading shown, (a) calculate the vertical deflections at P and Q, (b) calculate the support reactions (c) draw the bending moment diagrams for the beams. D A W broid W F (1) P broto L/2 L E (31) B L OTOTO 4/4 L L NO
