Consider a Class-A power amplifier as in the figure besides,
where the BJT has VBE 0.7V, B = 100, N = 2.5.
a/ Determine the Q-point and plot ACLL and DCLL on the
same coordinate system.
b/ Calculate the efficiency of this v W circuit?
Consider A Class A Power Amplifier As In The Figure Besides Where The Bjt Has Vbe 0 7v B 100 N 2 5 A Determine 1 (60.79 KiB) Viewed 53 times
+ Vcc=18V N:1 R2 w 8292 cı→00 LL w RL VI M 412 Re 192 w 1592 HI
