P } 8 . in. -4 in (a) in.

Post by answerhappygod »

P 8 In 4 In A In 1
P 8 In 4 In A In 1 (172.33 KiB) Viewed 97 times
The lap joint shown in the Figure is fastened by four rivets of 3/4-in diameter. If P is equal to 24,700 lb, determine the shear stress on the rivets and the bearing stress between the plate and the rivet. Assume that the applied load is distributed evenly among the four rivets and neglect friction between the plates.
P } 8 . in. -4 in (a) in.
Join a community of subject matter experts. Register for FREE to view solutions, replies, and use search function. Request answer by replying!
