NEED ASAP!! I WILL UPVOTE IF CORRECT!!
0000 00 ооо 100 mm A Holand WAB 3 rad/s 80 mm A.) Determine the angular velocity of member BC. O 2.01 rad/s 3.06 rad/s 3.25 rad/s 2.79 rad/s B.) Determine the velocity of C. O 0.31m/s 0.41m/s 0.57m/s D 0.51m/s C.) Determine the Velocity of point B. O 0.42m/s O 0.30m/s O 0.48m/s O 0.36m/s D.) Calculate the angle between the velocity of C and the velocity of C with respect to B. O 30.0 degrees 54.3 degrees 32.0 degrees 35.7 degrees E.) Calculate the velocity of C with respect to B. 0.32m/s 0.52m/s 0.45m/s 0.48m/s оооо 30° B 160 mm C
