The dynamic responses of CV vs MV in set point tracking are
shown in the following figures. For each case, whether the control
is good, and if not, which performance parameter is obviously bad
(choose one from rise time, settling time, decay ratio of
oscillations, offset, max dev of CV, IAE, MV overshoot)?
The Dynamic Responses Of Cv Vs Mv In Set Point Tracking Are Shown In The Following Figures For Each Case Whether The C 1 (167.55 KiB) Viewed 20 times
Controlled and manipulated variables Controlled and manipulated variables 0 | || Set point Controlled Manipulated 100 Time, (a) Set point Controlled Manipulated 100 Time, 1 (c) 200 200 Controlled and manipulated variables Controlled and manipulated variables Set point wwwwwwww 0 100 Time, 1 (b) Controlled Controlled my Manipulated 200 www Manipulated 100 Time, (d) 200
