For the position indicated in the figure, the manometer shows a
zero pressure value and the
piston touches the spring without compressing it. The spring has a
constant of 360 kN/m and the
relative density of the oil is 0.85. The diameter of cylinder A is
0.7 m and the diameter of cylinder B is
of 0.5, what will be the pressure read on the manometer when the
spring is compressed 50
cm.
For The Position Indicated In The Figure The Manometer Shows A Zero Pressure Value And The Piston Touches The Spring Wi 1 (101.2 KiB) Viewed 52 times
1.3m HA Suministro de aire 2m U
