Hi I have an assignment where I have to simulate a single phase full bridge rectifier with smothing capacitor. I have to

Post by answerhappygod »

Hi
I have an assignment where I have to simulate a single phase full bridge rectifier with smothing capacitor. I have to simulate it in PSCAD. can anyone helped with to optain the values of passive an active components and eventually simulation on PSCAD. thanks.
circuit figure attached.
