A rectangular slab of silicon is doped with 1022 m³ Boron (B) atoms. The intrinsic carrier concentration n; in silicon a

[answerhappygod]

A Rectangular Slab Of Silicon Is Doped With 1022 M Boron B Atoms The Intrinsic Carrier Concentration N In Silicon A 1 (456.56 KiB) Viewed 15 times

A rectangular slab of silicon is doped with 1022 m³ Boron (B) atoms. The intrinsic carrier concentration n; in silicon at 300K is 1.5x10¹6 m³ and it varies with temperature as T3/2exp(-Eg/2kT), where Eg-1.1eV is the bandgap energy, T is the absolute temperature in K and k is Boltzmann's constant. The silicon slab is 6 μµm long with a rectangular cross section of 2 µm ² (1 µm x 2 μm). Assume kT=0.026 eV and kT/q=0.026 V. Assume that the electron mobility is ue=0.04 m²/Vs and that the hole mobility is un=0.02 m²/Vs. (i) Evaluate the majority and minority carrier concentrations at 300 K and state the type of carrier (electrons or holes) Is this silicon p-type or n-type? (ii) If the temperature is raised to 360 K explain qualitatively the change in each type of carrier. (iii) Calculate the resistance of the slab described above at 300K and 360K.
