Add to o C(s) R(s) D(s) H(s) 10 K Consider the system given above with D(s) = ,G(s) = ,H(s) = 1 and answer (s+2)(s+4) th

[answerhappygod]

Add To O C S R S D S H S 10 K Consider The System Given Above With D S G S H S 1 And Answer S 2 S 4 Th 1 (200.77 KiB) Viewed 16 times

Add to o C(s) R(s) D(s) H(s) 10 K Consider the system given above with D(s) = ,G(s) = ,H(s) = 1 and answer (s+2)(s+4) the following questions and output signals of the system 2) What should the sampling period of the digital control system for K=1 be at most considering the primary strip in which the continuous closed-loop poles in s-domain should lie? C(Z) 3) Find the discrete-time transfer function where K is remained as a parameter. mic ctable via G₂OH(S) G(s)
