a) In your final year design project, a flash separator is used to separate liquid stream containing hydrocarbon mixture

[answerhappygod]

A In Your Final Year Design Project A Flash Separator Is Used To Separate Liquid Stream Containing Hydrocarbon Mixture 1 (198.28 KiB) Viewed 11 times

a) In your final year design project, a flash separator is used to separate liquid stream containing hydrocarbon mixture of 20 moles% methanol, 50 moles% acetonitrile and the rest is nitromethane. The mixture flashes into two phases inside the drum where the pressure and temperature are maintained at 152.83 kPa and 370 K. i. Determine the new flash pressure required if you want to lower the liquid to feed ratio to 0.25. (6 marks) ii. Calculate the corresponding composition of the liquid and vapor phases after pressure adjustment. (9 marks) 3 B In Pişat (kPa) = A - T(K) + C A 16.5785 B 3638.27 с -33.65 Species Methanol Acetonitrile Nitromethane 14.895 3413.1 -22.627 -45.55 14.7513 3331.7
