A compacted fill of 8.5 m height is to be placed over a large area. The soil profile under the filled area is shown in the figure below.Oedometer tests on samples from points A and B produced the following results: A representative set of cone data at a site is shown in Figure below. A square footing 3 m wide imposing an applied stress of 217 kPa is to be located 1 m below ground level at this site. Determine (1) the ultimate bearing capacity (2) the settlement of the footing one year after construction The bulk unit weight of the sand is 17 kN/m'. Groundwater level is 8 m below the ground surface. (MPa) 15 5 10 20 25 30 0 2 4 Depth (m) 6 B 10 12 14 16 18 hy
