(b) Find the vertical deflection of Joint C due to applied load only.
(c) Find the horizontal deflection of Joint C due to temperature increase of T = 100 C in member BD only.
Tablulate your calculations as shown below
- A Find The Horizontal Deflection Of Joint C Due To The Applied Load Only B Find The Vertical Deflection Of Joint C 1 (26.14 KiB) Viewed 14 times
- A Find The Horizontal Deflection Of Joint C Due To The Applied Load Only B Find The Vertical Deflection Of Joint C 2 (26.14 KiB) Viewed 14 times
60 Kn to the right
1.2 m height
0.9 m base
3. Dat the trussen in Figure I have sectional area of A mohou modulus of elasticity - 200 i me Method allection of om de to the applied load only election sont due to applied only hotellection of joint due o temperature increase of AT - 100 in Figure 1
