179 73 pole The truss shown is supported by a pin support stand by a roller opport at H. a) Determine the reactions at Fund b) Identify all zero-force members (remember that if a member is szero-force member for the case of loading considered, this means that it is like if the member does not exist). c) Use the method of sections to determine the force supported by members BC, GC, and GH. All necessary Free Body Diagrams are graded 2 KN 2 KN 800 800 800 800 800 800 А B c D 800 E F 1 G All dimensions are in mm. 5 12 H 13
