and 03 3.13 Referring to Figure 3.9, let ro - 30 mm, n = 10 mm, 72 - 35 mm, 20 mm, and 01 - 45°. Calculate 02, 03, V, 02. for a 30 rad's cow. Use analytical vector methods. 3.14 Repeat Problem 3.13 for 8, = 60°.
3.13 Referring to Figure 3.9, let to 30 mm, 10 mm, ry 35 mm, 73 20 mm, and 8, = 45°. Calculate 8, 03, V, W, and wfor 30 rad/s ocw. Use analytical vector methods. I 3.14 Repeat Problem 3.13 for e 60° 2r35 and fo linkage of our
Section 3.4 Application of Analytical Vector and Matrix Methods to Linkages 179 ER Link 3 B I Link Frame FIGURE 3.9 Analytical study of a four-bar linkage
