a)calculate the shaft speed no2 and no 3 taking into account the gear ratio.
b)calculate the forcing frequencies for the machine. motor speed 300rpm ,gear no1 (30 teeth) drives gear No 2 (90t teeth),gear no 2 is directly connected to gear no 3 ,gear no 3 (20 teeth) and drives gear no 4 (90 teeth), motor fan 6 fin ,motor rotor 150 bar
A Calculate The Shaft Speed No2 And No 3 Taking Into Account The Gear Ratio B Calculate The Forcing Frequencies For Th 1 (106.97 KiB) Viewed 16 times
Im Ho du Hit the gea uestion 4.2 Re-Draw this table 1.1 and calculate the forcing frequencies for the machine indicated in diagram 1.1. 1 Shaft 3 No2 fa or Shaft 1 2 No1 fan, 12blade Shaft 2 am 1.1
