Problem 1 (30): Dr. is working in the thermal laboratory where oil is stored at 150°C in a spherical container of 300 cm

[answerhappygod]

Problem 1 30 Dr Is Working In The Thermal Laboratory Where Oil Is Stored At 150 C In A Spherical Container Of 300 Cm 1 (42.66 KiB) Viewed 6 times

Problem 1 (30): Dr. is working in the thermal laboratory where oil is stored at 150°C in a spherical container of 300 cm of internal diameter, the container was made with 3-cm-thick cooper (k - 386 W/m°C). The tank is covered with 8. cm-thick glass wool insulation (k - 0.05 W/m°C). Determine the heat loss to the surroundings at Toz-28 °C by natural convection and radiation, with a combined heat transfer coefficient of ha - 150 W/m2oC. Taking the heat transfer coefficient of the oil h1 - 1200 W/m2oC. a ri- 300 cm OL OL 12- 303 cm ry" 311 cm Top-28°C hy- 150 W/m2 °C ra Too1- 150°C h.- 1200 W/m2
