(b) The open-loop transfer function (OLTF) of a unity feedback servomechanism system is given by: G(s)H(s) = K(s + 10) 5
-
answerhappygod
- Site Admin
- Posts: 899603
- Joined: Mon Aug 02, 2021 8:13 am
(b) The open-loop transfer function (OLTF) of a unity feedback servomechanism system is given by: G(s)H(s) = K(s + 10) 5
(b) The open-loop transfer function (OLTF) of a unity feedback servomechanism system is given by: G(s)H(s) = K(s + 10) 53 Where is the open-loop gain. 17 marks) (sketch the Nyquist diagram of the system in the GHGW)-plane and investigate the system's behaviour for varying Kvalues. 16 marks) (H) using the results from Part (II) show that the system is stable for K> 5.F. Validate your answer using the Routh-Hurwitz stability criterion 14 marks)
