QUESTION 2: A closed-loop control system is given in the figure
below. System one the order and transfer function πΊπ =
[π^(-2π )]/π +1 it is given as. The sampling period is 1 second.
Question 2 A Closed Loop Control System Is Given In The Figure Below System One The Order And Transfer Function Gs 1 (22.49 KiB) Viewed 13 times
Design a digital PI controller with a damping ratio of 0.5 and a
ratio of Wd/Ws=1/10(the number of samples per cycle of damped
sinusoidal oscillation). Get the unit-digit system answer and draw
it (by typing the gain coefficients that you found in the
controller design instead of the pulse transfer function).
c(t R(t) Digital Controller ZOH System Ρ R(S) R(2) G(s) C(s) C(2) Gd(z) PI
