The parameters of a parallel-plate air-filled lossless transmission line are h = 0.1327 cm, w = 1 cm, l = 10m, H, = 1, €
-
answerhappygod
- Site Admin
- Posts: 899603
- Joined: Mon Aug 02, 2021 8:13 am
The parameters of a parallel-plate air-filled lossless transmission line are h = 0.1327 cm, w = 1 cm, l = 10m, H, = 1, €
The parameters of a parallel-plate air-filled lossless transmission line are h = 0.1327 cm, w = 1 cm, l = 10m, H, = 1, €r = 1 where l is the line length. The line is used to connect a source of vy(t) = 100V2cos(21106t)V and internal impedance 2g = 100 to a load of Zų = 50 + j 50N. a) Find the line characteristic impedance 20. d) Find the input impedance of the line Zin. e) Calculate the voltage reflection coefficient r. f) Find V and write V (z) and I(z) the voltage and current phasors. g) What is the voltage VL at the load? h) What is the average (real) power delivered to the load?
