11.For an RC Circuit: a. Using information from the graph, find τ b. If R= (last 4 digits of your ID) Ω, calculate C (use the result from Part (a) c. (1p) Show, by dimensional analysis, that τ has units of time.
a. Using information from the graph, find τ
b. If R= (last 4 digits of your ID) Ω, calculate C (use the result from Part (a) c. (1p) Show, by dimensional analysis, that τ has units of time.
1 (52.11 KiB) Viewed 34 times
graphic: voltage vs time
iene unidades de tiempo. Voltaje (v) (0.0157, 3.975) + +(0.0079, 2.48) (0.0074, 0.00) 0 tiempo (s) Gráfica: Voltaje Vs Tiempo del Circuito RC
