2. (30 pts.) The pipe structure is held in place by a fixed support at 0. The forces Fp and Fc are applied as shown in t
2. (30 pts.) The pipe structure is held in place by a fixed support at 0. The forces Fp and Fc are applied as shown in the figure. FB = (-300i + (-90lj + 100)k) N; Fc = (150i + 120j + (-200]k) N. Using a vector approach, calculate the reactions at 0. Express your reactions in 3D Vector Notation Fв z 0.3 m B Fc 0.5 m 0.4 m in Equ
