How can you tell if its low pass or high pass?
The name of the filter and the value of the resistor for a filter that employs a 10 nF capacitor and filters out low frequency signals while achieving a half power frequency of 150 kHz are Low pass 1020 ohms High pass, 1300 ohms High pass, 106 ohms Low pass, 106 ohms
