1) The figure below shows a mass system connected with a spring. It has a mass of 0.5 kg and spring constant of 5 N/m. A
1) The figure below shows a mass system connected with a spring. It has a mass of 0.5 kg and spring constant of 5 N/m. At t = 0 the mass is released from a point 50 cm above the equilibrium position without an initial velocity. Assuming there is no damping and friction losses. y=A m y=-A... a) Obtain a general displacement solution for the free oscillator with the initial conditions in Matlab. b) Create a graph to show the displacement for 10 s. c) Overlay the velocity plot onto the displacement plot and show the magnitude of velocity on the right side of the plot (second y axis)
