Using the CPT log in Figure 4.22, determine the SBTn for the soil stratum located between depths of 28 and 48 ft, and compute the equivalent SPT N-value. Assume the groundwater table is below 48 ft and the unit weight of the soil above 48 ft is 120 lb/ft².
Cone Bearing, q (Kg/cm²) Neo 12 = 11 10 L in L 9- 8 7 6 L T T T T 4 3 2 1 0 0.001 Robertson and Campanella, 1983 www 0.005 0.01. 8 Do Lul 0.05 0.1 0.5 Mean Particle Size, Dao (mm) L 1 08 O Kulhawy and Mayne, 1990 Lub 5 10
