2) A parking lot entrance system is described below. Before a car gets into the parking lot, the driver must get a ticket from a machine. To do that, the driver presses a button (11), and a ticket is printed (01). After this, the gate opens (02), and the car enters the parking lot. A sensor (12) placed next to the gate sends an ON signal as long as it senses the car during the ticketing operation, and when the car passes in front of it, it starts generating an OFF signal which causes the gate (02) to close. For security purposes, when a ticket is printed, a camera placed at a suitable location is activated (03) and records the image of the car. Draw the ladder logic diagram for this system. Ticket Machine Sensor Camera Car Gate
