Consider the dynamic system shown below. The input f(t) is a force applied to mass m2. The coefficient of viscous fricti

Post by answerhappygod »

Consider The Dynamic System Shown Below The Input F T Is A Force Applied To Mass M2 The Coefficient Of Viscous Fricti 1
Consider The Dynamic System Shown Below The Input F T Is A Force Applied To Mass M2 The Coefficient Of Viscous Fricti 1 (57.09 KiB) Viewed 49 times
Consider the dynamic system shown below. The input f(t) is a force applied to mass m2. The coefficient of viscous friction between all surfaces of contact is b. b m2 f(t) k w b mi A) Find the transfer function between the input force and the displacement of mass m2. B) For an unit step force imiput, what is the final displacement of the mass m2? Analyze the result. Does it make sense for the system under study? Explain.
