Question 1 (a) The power pattern of the major lobe of an antenna is given by, (O SO S T/2, 0 5 0 5 2T). Estimate the val

Post by answerhappygod »

Question 1 A The Power Pattern Of The Major Lobe Of An Antenna Is Given By O So S T 2 0 5 0 5 2t Estimate The Val 1
Question 1 A The Power Pattern Of The Major Lobe Of An Antenna Is Given By O So S T 2 0 5 0 5 2t Estimate The Val 1 (112.11 KiB) Viewed 35 times
Question 1 (a) The power pattern of the major lobe of an antenna is given by, (O SO S T/2, 0 5 0 5 2T). Estimate the value of beam solid angle 12A and maximum directivity D of the antenna. State the assumption(s) used in the estimation. C4/CLO1/PL01 (10 marks) (b) Construct a two-dimensional field and power antenna pattern. Indicate in the diagram the relevant information required to measure the HPBW and FNBW. C3/CLO1/PL01 (10 marks) (c) What criteria is required for an earth antenna that is used to communicate with a probe on planet Mars. Suggest an antenna for the above requirement. C5/CLO1/PL01 (5 marks)
Join a community of subject matter experts. Register for FREE to view solutions, replies, and use search function. Request answer by replying!
