Build a Single-phase full-wave controlled rectification circuit with RL load in MATLAB.

Post by answerhappygod »

Build a Single-phase full-wave controlled
rectification circuit with RL load in MATLAB.
Build A Single Phase Full Wave Controlled Rectification Circuit With Rl Load In Matlab 1
Build A Single Phase Full Wave Controlled Rectification Circuit With Rl Load In Matlab 1 (86.7 KiB) Viewed 46 times
(1) Calculate the theoretical output voltage (average value) while adjusting firing phase shift form 30, 60, 90, 120, and fill it in the form. (2) Observe the waveform of output voltage and thyristor voltage while adjusting firing phase shift form 30, 60, 90 and 120, then record the value of output voltage.
