There is an 18 m long truss with the vertical and horizontal loadings shown. There is a pinned support at the left end a

Post by answerhappygod »

There Is An 18 M Long Truss With The Vertical And Horizontal Loadings Shown There Is A Pinned Support At The Left End A 1
There Is An 18 M Long Truss With The Vertical And Horizontal Loadings Shown There Is A Pinned Support At The Left End A 1 (28.06 KiB) Viewed 35 times
There is an 18 m long truss with the vertical and horizontal loadings shown. There is a pinned support at the left end and a-roller at the right. What is the internal force in the member LF? a) 15.7kN, compression b) 15.7kN, tension C) 8.7kN, tension d) 0 e) 8.7kN, compression
Join a community of subject matter experts. Register for FREE to view solutions, replies, and use search function. Request answer by replying!
