i. The generator polynomial of a cyclic code is given as g(x) = 1 + x + x4 Draw the diagram of feedback shift register e
-
- Site Admin
- Posts: 899559
- Joined: Mon Aug 02, 2021 8:13 am
i. The generator polynomial of a cyclic code is given as g(x) = 1 + x + x4 Draw the diagram of feedback shift register e
i. The generator polynomial of a cyclic code is given as g(x) = 1 + x + x4 Draw the diagram of feedback shift register encoder for the Linear Cyclic code (3 Marks) ii. Illustrate the encoding procedure with the message vector [10111 ] by using the states of the register(the right most bit is the earliest bit) and obtain the final codeword. (7 Marks) jii. Verify the codeword obtained in part c polynomial division method (3 Marks) iv. Derive a syndrome computation circuit for this code. (2 Marks) v. Let r=[ 1001101 ) be a received vector. Compute the syndrome of r(t). Display the contents of the syndrome register after each digit of r has been shifted into the syndrome computation circuit. (6 Marks) Compare the syndrome computation performed part v by performing polynomial division method. (4 Marks) vi.
