Question 3: (10 marks) Consider the circuit of Fig.3. W is Vs R = 10 L = 100 mH C = 225.33 uF Fig 3. a) write a matlab code that provides on the same page two semilog plots one for the magnitude and the other for the phase angle in degree) of the ratio Vs/ls versus the frequency of the current source (is) if such frequency is varied between 10 Hz to 5000 Hz in step of 10 Hz. b) If the current source is has the expression is = 15 sin(200TT t) + 5 cos(20001 -TT/4) + 15 cos(10000T +60°) A Draw in one page two figures. One figure contains the time varying waveform of the current (is) versus the time (t); label this figure "Input Current", label the xaxis "Time (msec)" and the yaxis "Current (A)". The second figure contains the time varying of the voltage (vs) versus the time (t); label this figure "Output Voltage". label the xaxis "Time (msec)" and the yaxis "Volage (V)". For both figures, vary the time (t) between 0 and 5 ms in step of 10 S. Matlab Code:
