Instructions: Do the task usingMultisim application so that you could place yourgraph with measured maximum Vin and maximum Vout without anyclippings. Thank you.
- Bjt Amplifier Circuits Activity Instructions Do The Task Using Multisim Application So That You Could Place Your Graph 1 (71.13 KiB) Viewed 23 times
Construct the Common Collector simplifier shown in fig.3 Vin C1 XFC1 35E E ō 10μF R1 330k VCC 12V R2 1k0 Q1 Fig.3 Common Collector Amplifier Connect a signal generator with 500mvp and 1khz frequency to Vin. Connect the oscilloscope to the input and output terminal of the amplifier as shown in fig.3. Adjust Vin so that Vout reaches its maximum value. 2N39042 Vout de R3 10μF 1000 VCC 12V LR2 $180 Vout RI 330K เอ Q1 Vin C1 HE 10μF 23.304 HE 1000 XBC1 DAT # Fig.4 Input Output Voltage Measurement Place your graph here with measured maximum Vin and maximum Vout without any clippings. Include the peak to peak measured value using the probe to the graph. Construct the Common Base simplifier shown in fig.5 ZFG1 MSN C1 E 10μF Vin Vin LR1 >330k C1 #f 10μF R4 300k R1 >330k VCC LR4 3300kΩ R2 ΣΥΚΩ Q1 12V Fig. 5 Common Base Amplifier 2N3904 R3 10002 VCC Q1 36 10μF R2 21kQ C2 Vout 12V C2 카 R3 1000 10μF 2N3904 Vout Fig.6 Input and Output Voltage Measurement ZSC1 Ex Tip Connect a signal generator with 1vp and 1khz frequency to Vin. Connect the oscilloscope to the input and output terminal of the amplifier as shown in fig.6. Adjust Vin so that Vout reaches its maximum value. www
Place your graph here with measured maximum Vin and maximum Vout without any clippings. Include the peak to peak measured value using the probe to the graph. Using the data you acquired differentiate the three amplifier circuits configurations.
