The shaft shown below is 1060 steel that was quenched and tempered at 800° F. It rotates at 3 rpm and does not carry any applied torque. Determ. momentiron-metors) at the axia!!ocation of in- . LMI...... IVV LVII. ܀ Flb 30 mm 30 mm 20 mm 100 mm dia 120 mm dia. 100 mm dia Fillet, radius r -Ib & Ib
1 pts Determine yield strength for the shaft (units MPa). 1 pts Determine factor of safety for static yield at the fillet if nominal bending stress is 154 MPa, static stress concentration factor is 2.53 and yield strength is 750 MPa. 1 pts The shaft rotates at 3 rpm. Determine minimum number of days for continuous operation to reach the endurance limit for the shaft at 10 stress reversals. 1 pts 1060 steel quenched and tempered is typically considered to be a material. O ductile brittle
