Problem 7.3 The pressure vessel shown in figure 7.3 is of radius r=200 mm and thickness t=5 mm. The helical angle of the shown welding is ß-25 deg. For a maximum allowable normal stress perpendicular to the welding w,allow =100 N/mm², determine the maximum nominal internal pressure the vessel can sustain Ans: p<4.24 N/mm²
