Using LabVIEW: - Generate 2 waves: One sine-wave (x(t)) and one square-wave (y(t)) of the same frequency f - Multiply th

[answerhappygod]

Using Labview Generate 2 Waves One Sine Wave X T And One Square Wave Y T Of The Same Frequency F Multiply Th 1 (31.59 KiB) Viewed 49 times

Using LabVIEW: - Generate 2 waves: One sine-wave (x(t)) and one square-wave (y(t)) of the same frequency f - Multiply these signals to obtain z(t)=x(t)y(t) - Input z to a RMS-value measuring instrument and to a mean-value measuring instrument - Change the phase of x(t) between 00-1800 and observe the change in the RMS and mean-values of z - Comment on the results - Explain the steps you go with LabVIEW while configuring your setup. - Give numerical values for your experiment.
