The storage-outflow relationship of a reservoir is given in Table 1. The inflow hydrograph is given in the Table 2. Using the Puls method, determine the outflow hydrograph fort this reservoir. Draw the inflow and outflow hydrographson a milimetric paper. Specify quantitatively the effects of the flood routing. Table1: Storage-outflow relationship Q(m³/s) 10 20 30 40 50 60 70 80 S(1000m³) 60 120 200 270 350 400 480 Table2: Inflow hydrograph Time(hr) 0 2 4 6 10 12 14 16 1(m³/s) 6 36 46 35 25 20 15 10 NOTE: 1) All the calculations and drawings should be presented with handwriting. 2) Numerical results will be given with one decimal 3) The needed milimetric paper is provided below 00 550 18 LO
