Q2. Elements (1) and (2) are subjected to the distributed loads shown below. a) Replace the distributed loads by equival

[answerhappygod]

Q2 Elements 1 And 2 Are Subjected To The Distributed Loads Shown Below A Replace The Distributed Loads By Equival 1 (24.79 KiB) Viewed 18 times

Q2. Elements (1) and (2) are subjected to the distributed loads shown below. a) Replace the distributed loads by equivalent loads at nodes 3, 4 and 5? (%10) b) Calculate the element stiffness matrix for element 1 and element 2? (%20) c) Assemble the global stiffness matrix? (20) 100 8 50 Nicm 3 5 (x25.y-2.0) 2 1 2.0 cm 2 -1.5 cm
