Find the following values:
a. The vertical component of reaction force on point 1
b. The vertical component of reaction force on point 3
c. The horizontal component of reaction force on point 1
d. The horizontal component of reaction force on point 3
(Include direction)
Find The Following Values A The Vertical Component Of Reaction Force On Point 1 B The Vertical Component Of Reaction 1 (18.68 KiB) Viewed 38 times
(Ignore the weight of the beam and the support.)
4 kN 1.5m 1.5m 2 1 3 1.5m 4
