Q.2 The pin-jointed truss shown has design effects as indicated along the respective members (where T=Tension and C=Compression). The client wants to use a single section for all the members of the truss. List the design effects in tension and compression and recommend the lightest CHSin S355 that can be used for the whole truss, assuming connection are made by welding. Show detailed calculation for all essential design check. 740 KN(T) Height (m) 610 KN(T) 530 KN(C) OE LA 7 Length (m)
