1. A causal LTI system is described by 1-1/2-1 H(z)= 5 1-2-¹2-2 (a) Draw the block diagram for this system in Direct For
1. A causal LTI system is described by 1-1/2-1 H(z)= 5 1-2-¹2-2 (a) Draw the block diagram for this system in Direct Form II. (3) the result of part (a), what is the type of this Alter (PF, HPP or BPF)? (b) Draw the corresponding Signal Flow Graph (SFG) with minimal delay. (5) (c) Draw the Parallel Form only with 1" order sub-systems. (4)
